Symphony I/O Mk II HD is designed for the Pro Tools HD user who needs a multi-channel audio interface with the best sound quality at an incredible cost per channel value. Whether using a Mac or PC based studio, Symphony I/O Mk II HD can connect directly to the Digilink port on your Pro Tools HDX, Pro Tools HD Native or Pro Tools Core/Accel systems.
Symphony I/O Mk II HD can be utilized alongside or in place of Avid® or Digidesign® interfaces for Pro Tools HD. In fact, each I/O module installed in Symphony I/O Mk II HD appears and functions in Pro Tools HD the same if it were a separate Avid HD I/O interface, so set up is easy and you can take advantage of important Pro Tools features such as sample-accurate delay compensation.
A single Symphony I/O Mk II HD unit can have up to 32 simultaneous analog I/O, so you can have more channels with less rack gear. Need even more channels? You can utilize multiple units simultaneously, with one Symphony I/O Mk II HD per every Pro Tools HD DigiLink port in your system. Calibrating your I/O is easy with Symphony I/O Mk II HD’s front panel touchscreen.
Highlights:
- Best performance of any multi-channel Pro Tools HD interface
- Best cost per channel value of any Pro Tools HD interface solution
- Connects directly to any Pro Tools HD system via DigiLink port (Mac or PC)
- Emulates Avid HD I/O interface, including sample-accurate delay compensation
- Connect multiple units in a single system (1 unit per HD Digilink port)
- Easy I/O calibration with front panel touchscreen
2x6 card:
- Inputs
- Analog IN: 2 balanced inputs on 2 female XLR connectors
- AES IN: Stereo input on 1 female XLR connector
- Optical IN: Supports ADAT, SMUX & S/PDIF:
- ADAT: 8 channels 44.1-48 kHz on 1 Toslink connector
- SMUX: 4 channels 88.2-96 kHz on 1 Toslink connector
- S/PDIF: 2 channels, up to 96 kHz on 1 Toslink connector
- S/PDIF Coax IN: 2 channels, up to 192 kHz on 1 RCA connector
- Outputs
- Analog OUT: 6 balanced outputs on 1 DSUB 25-pin connector
- AES OUT: Stereo output on 1 male XLR connector
- Optical OUT: Supports ADAT, SMUX & S/PDIF:
- ADAT: 8 channels 44.1-48 kHz on 1 Toslink connector
- SMUX: 4 channels 88.2-96 kHz on 1 Toslink connector
- S/PDIF: 2 channels, up to 96 kHz on 1 Toslink connector
- S/PDIF Coax OUT: 2 channels, up to 192 kHz on 1 RCA connector
Connection: - Pro Tools HD Core card
- Pro Tools Accel PCI card
- Pro Tools HD Native PCI card
- Pro Tools HD Native Thunderbolt
- Pro Tools HDX PCI card
